BO Motor 60 RPM Dual Shaft Gear Motor 1:220
₹47.00 (Inclusive of GST)
28BYJ-48 Stepper Motor – 5V
₹98.00 (Inclusive of GST)
- Type: Unipolar Stepper Motor
- Operating Voltage: 5V DC
- Step Angle: 625°/64 reduction (final ~0.088° per step)
- Gear Reduction Ratio: 1:64
- Phase: 4-phase
- Rated Current: < 240 mA
- Shaft Type: Single Shaft
- Shaft Diameter: 5 mm (D-type)
- Torque: Suitable for light-duty precision applications
- Connector Type: 5-pin JST compatible
- Low noise and low power consumption
Description
- The 28BYJ-48 5V Stepper Motor is a compact, low-cost unipolar geared stepper motor widely used in automation, robotics, and embedded systems.
- With an internal 1:64 gear reduction, it offers very fine control with an effective step angle of approximately 0.0879°, allowing precise positioning.
- Designed for low-power applications, it operates smoothly at 5V, making it ideal for direct use with microcontrollers such as Arduino, Raspberry Pi, and ESP boards.
- Its built-in gearbox increases torque output while reducing load on the motor, ensuring stable and repeatable movement.
- Highly durable and reliable for continuous duty cycles, DIY projects, and slow, controlled motion systems.
- Often paired with ULN2003 stepper driver modules for easy interfacing.
PACKAGE INCLUDES:
- 1 × 28BYJ-48 Stepper Motor (5V)
Additional information
| Weight | 30 g |
|---|
Reviews (0)
Application
- Robotics and mechatronics projects
- Camera sliders and pan-tilt systems
- 3D printers (non-load-bearing functions)
- Air conditioning flap movement
- CNC light-duty mechanisms
- Home/office automation
- Analog gauges and control knobs
- Educational and prototyping projects
- Smart lock mechanisms
- Timed mechanisms and rotating displays
TECHNICAL SPECIFICATIONS
| Parameter | Value |
| Motor Type | 4-phase Unipolar Stepper |
| Operating Voltage | 5V DC |
| Rated Current | < 240 mA |
| Step Angle (Internal) | 5.625° |
| Gear Reduction Ratio | 1:64 |
| Effective Step Angle | ~0.088° |
| Coil Resistance | 50 Ω (per coil) |
| Shaft Diameter | 5 mm (D-Type) |
| Shaft Length | 10 mm |
| Motor Diameter | 28 mm |
| Cable Length | ~20 cm |
| Weight | 35 g |
| Shipping Weight | 0.05 kg |
| Shipping Dimensions | 5 × 5 × 4 cm |
Reviews
There are no reviews yet.
